This video introduces to DigiSILENT powerfactory. DigiSILENT PowerFactory is a leading power system analysis software application for use in analysing generation, transmission, distribution and industrial systems. It covers the full range of functionality from standard features to highly sophisticated and advanced applications including wind power, distributed generation, real-time simulation and performance monitoring for system testing and supervision.

This video shows the how to make graphic diagrams/Grid systems and do basic load flow analysis on it. Furthermore it allows us to study the effects on variation of some factors like Active power, Reactive power, Voltage, Frequency Without physically having them. This software greatly helps in increasing the efficiency of the system

PowerFactory Applications DIgSILENT has set standards and trends in power system modelling, analysis and simulation for more than 25 years. The proven advantages of PowerFactory software are its overall functional integration, its applicability to the POWER TRANSMISSION The transmission grid is currently undergoing a major change to reliably accommodate increasing amounts of nondispatchable resources while maintaining operational efficiency and system-wide cost. The displacement of less flexible base-load generation by asynchronous wind and solar power generators imposes new challenges on the ability of the grid to maintain system stability. PowerFactory offers a complete suite of functions for studying large interconnected power systems and addressing these emerging needs. Its fast and robust simulation algorithms can be applied to any AC or DC network topology and support the simulation of new technologies such as converter-based power generation, FACTS, voltage-sourced converters (VSC), HVDC cables and overhead lines, DC breakers, filters, and various types of MW- and Mvar-controllers and virtual power plants. PowerFactory is also perfectly suited to transmission system operation planning. It integrates a comprehensive set of tools to support automatic and parallel grid safety analysis such as ENTSO-E D2CF/ DACF/IDCF, and outage planning. Multiple interfaces (API, DGS, CIM) and flexible scripting languages (DPL, Python) enable smooth integration with existing systems. POWER DISTRIBUTION Different phasing technologies, such as single-wire earth return, two-phase, bi-phase or classical three-phase systems, have created a need for multi-phase distribution power system modelling. PowerFactory provides comprehensive modelling features for studying all kinds of electrical networks with different phasing technologies, meshed or radial topologies and railway supply systems connected to public distribution systems. In order to reduce network unbalance, improve quality of supply and optimise distribution networks, PowerFactory offers a large variety of functions, such as multi-phase load flow analysis, short-circuit analysis (IEC 60909, ANSI C37 and multiple fault analysis), harmonic analysis, quasi dynamic simulation, time-domain simulation, optimal power restoration and reliability assessment. Other standard features include the modelling of distributed generation and virtual power plants, voltage drop analysis, consideration of LV load diversity, daily load and generation profiles and easy-to-use protection coordination functionality. OTHER IMPORTANT ASPECTS: Tie open point optimisation Optimal capacitor placement Voltage profile optimisation for bi-directional power flows Geographic diagrams (GPS-based) with background maps GIS and SCADA integration.
